RB953GS-5HnT-RP
RouterBOARD 953GS-5HnT-RP is our first product with 5GHz 3x3 MIMO Triple Chain support. It has a powerful (up to 1600mW!) Atheros QCA9558 CPU 802.11a/n wireless support with three RPSMA connectors.
RB953GS-5HnT is equipped with a new Scorpion 720Mhz CPU, 128MB RAM and three Gigabit Ethernet ports, to take advantage of high-speed 3x3 MIMO wireless. Moreover, it comes with two SFP cages to accommodate FTTH and fiber ring requirements.
Handy additions are two miniPCI-express slots and two SIM slots, for multiple 3G/4G connections or wireless expansion.
Unit comes with preinstalled RouterOS Level5 license.
Product specifications
| Details |
| Product code |
RB953GS-5HnT-RP |
| CPU nominal frequency |
720 MHz |
| CPU core count |
1 |
| Size of RAM |
128 MB |
| 10/100/1000 Ethernet ports |
3 |
| MiniPCI-e slots |
2 |
| Wireless standards |
802.11a/n |
| Wireless chip model |
QCA9558 |
| Number of USB ports |
1 |
| Power Jack |
1 |
| Supported input voltage |
8 V - 30 V |
| PoE in |
Yes |
| Voltage Monitor |
Yes |
| PCB temperature monitor |
Yes |
| Dimensions |
183x105x24mm |
| Operating System |
RouterOS |
| Operating temperature range |
-40°C .. +70°C tested |
| License level |
5 |
| CPU |
QCA9558 |
| Max Power consumption |
25W |
| SFP ports |
2 |
| USB slot type |
USB type A |
| Supported Voltage |
PoE in: 8-30V, Power jack: 8-30V DC |
| Number of chains |
3 |
| Serial port |
RS232 |
| Storage type |
NAND |
| Storage size |
128 MB |
Wireless specifications
| 5 GHz |
| |
TX |
RX |
| 6MBit/s |
32 |
96 |
| 54MBit/s |
30 |
81 |
| MCS0 |
32 |
96 |
| MCS7 |
29 |
77 |
wireless parameters may be limited in software, depending on your local regulatory limitations
Performance test results
| RB953GS-5HnT-RP |
QCA9550 1G all port test |
| Mode |
Configuration |
1518 byte |
512 byte |
64 byte |
| kpps |
Mbps |
kpps |
Mbps |
kpps |
Mbps |
| Bridging |
none (fast path) |
162.4 |
1,972.2 |
170.8 |
699.6 |
370.2 |
189.5 |
| Bridging |
25 bridge filter rules |
162.4 |
1,972.2 |
111.8 |
457.9 |
99.9 |
51.1 |
| Routing |
none (fast path) |
162.4 |
1,972.2 |
317.4 |
1,300.1 |
370.2 |
189.5 |
| Routing |
25 simple queues |
162.4 |
1,972.2 |
174.2 |
713.5 |
176.2 |
90.2 |
| Routing |
25 ip filter rules |
60.2 |
731.1 |
62.8 |
257.2 |
61.8 |
31.6 | |
